Blog 28 : Colour Matters

Colours by the same name….part 2!

I’m back at last! I have decided to continue on from Blog 25 which discussed Quinacridone Gold across three brands and how very different they all were. It is very easy to make the mistake of thinking different brand pigments will be the same if they have the same name or a very similar name. Some even have the same pigment index number!

In this blog I will be looking at a number of pigment colours across the Daniel Smith and the Winsor & Newton range. All but one have identical names but as you will see many of them are quite different. One colour even shows a difference in temperature, one is warmer and the other cooler. Some are more intense than others, five are completely different!

I am a big fan of W&N as the colour selection, where primaries are concerned, suits me well. Don’t get me wrong I like DS pigments too. DS pigments are beautifully intense and I especially like their iridescent range. These are great for adding shine to butterfly wings. I just feel there is too much choice in the DS range as it is possible to mix every colour you need with 3 blues, 3 reds and 3 yellows. When you mix with primaries, I really don’t think you need 25 reds to choose from, do you? There are also 13 violets in the DS range and I only use 2 from the W&N range, Winsor Violet and Perylene Violet. Some pigment colours across both brands make you think, do you really need them? W&N Ultramarine Violet for instance, why not add a little Winsor Violet to French Ultramarine? Cobalt Violet….a little Quinacridone Magenta mixed with Cobalt Blue will do the trick! Anyway, it’s food for thought.

I have selected 25 W&N pigments for my palette and one DS, Lemon Yellow. The only reason this yellow is there is because it is very like cool Winsor Lemon but DS Lemon Yellow is transparent, not semi-transparent. I generally use 6-9 of my pigments at the most when painting, depending on the subject.

The colours with the same names (except one) that I have selected to compare across these two ranges are listed below:

New Gamboge
Indian Yellow
Quinacridone Gold
Quinacridone Red
Permanent Alizarin Crimson
Perylene Maroon
Burnt Sienna
Cobalt Blue
French Ultramarine
Indanthrene Blue (Indanthrone Blue)
Perylene Green
Perylene Violet

I have written an outline for each pigment below to show you the differences and qualities. As you will notice there are three DS pigments which are semi-transparent. I prefer to use transparent or semi-transparent pigments. Some of the differences here are huge but some are actually quite favourable!

(Note: Some photographs are not always a true representation. The DS transparency symbols are different to W&N. Their semi-transparent symbol is a circle which is half black and half white. W&N uses a square which is half white and black but in this brand it means semi-opaque).

New Gamboge
DS – Transparent PY97, PY110
W&N – Transparent PR209, PY150
DS – very close to the primary yellow with a slight orange bias. A lovely pure pigment similar to W&N Indian Yellow but nearer to the yellow spectrum.
W&N – a muted yellow, similar to Transparent Yellow with a very slight brown bias when at full colour. A little warmer than Transparent Yellow. Makes a beautiful pale cream/yellow when watered down.

Indian Yellow
DS – Transparent PY97, PY110
W&N – Transparent PO62, PY139
DS – a cool yellow with translucency. Not what I would consider an Indian Yellow, more like W&N Transparent Yellow. This pigment could be used as a transparent yellow.
W&N – a rich orange yellow, flows smoothly and makes beautiful cream/apricot tones when watered down. Great for mixing bright oranges.

Quinacridone Gold
DS – Transparent PO48, PY150
W&N – Transparent PR206, PV19, PY150
DS – a warmer, less muted version with a lovely golden glow. It has an orange bias.
W&N – a muted, duller QG with a strong yellow bias. Rich brown/gold when at full strength.

Quinacridone Red
DS – Transparent PV19
W&N – Transparent PR209
DS – a cool magenta/red resembling Permanent Rose (PV19). Quinadridone Red in the DS range is closest to Permanent Rose.
W&N – a warm primary red. The match for this red is Quinadridone Coral (PR209) in the DS range. It is quite a weak pigment in both ranges but a beautiful pink/red.

Permanent Alizarin Crimson
DS – Transparent PR177, PV19, PR149
W&N – Transparent PR206
DS – a rich intense version of this colour but made with three index colours. It has a slightly warm red bias compared the W&N version which is cooler.
W&N – a cool not as intense version which can look a little flat when watered down on some watercolour papers.

Perylene Maroon
DS – Semi-Transparent PR179
W&N – Transparent PR179
DS – a rich intense version of this colour. It has a slightly warm red bias compared the W&N version which appears a little cooler.
W&N – Nicely intense too. Very slightly cooler than the DS version.

Burnt Sienna
DS – Semi-Transparent PBr7
W&N – Transparent PR101
DS – a very different Burnt Sienna to W&N and it appears to granulate. It is also semi-transparent.
W&N – one of my favourite reds. A much warmer version than DS. It is more like Pompeii Red (PBr7) in the DS range. I would add a tiny bit of Transparent Yellow (DS Indian Yellow) to Pompeii Red to make it a perfect match!

Cobalt Blue
DSSemi-Transparent PB28
W&N – Semi-transparent PB28
DS – this appears to granulate a little more than the W&N version and is very, very slightly cooler despite having the same index number.
W&N – a lovely middle blue, granulating. There seems to be a very slight difference but it is minimal.

French Ultramarine
DS – Transparent PB29
W&N – Transparent PB29
DS – a pure primary blue slightly more intense than the W&N version. Granulates.
W&N – a vibrant primary blue with no bias. Granulates. The only difference here is intensity of pigment.

Indanthrene Blue & Indanthrone Blue
DS Indanthrone – Transparent PB60
W&N Indanthrene – Semi-transparent PB60
DS – Indanthrone Blue is more like royal blue compared to Indanthrene Blue. It has a very slight red bias.
W&N – this version is very different to the DS version. It is a deeper blue with a very slight green bias. They both have the same index number though!
These are a nice option for a choice of warm or cool dark blue!

Perylene Green
DS – Semi-Transparent PBk31
W&N – Transparent PBk31
DS – very slightly warmer than W&N. It is semi-transparent. Mix it with a rich red like Pyrrol Crimson for a true black.
W&N – this version is very similar but it has a very slight blue bias. It is totally transparent as opposed to semi-transparent. Add a rich red like Permanent Carmine for a true black mix.

Perylene Violet
DS – Transparent PV29
W&N – Transparent PB29
DS – a rich pigment but it is more muted than the W&N version, that is, it has duller appearance.
W&N – slightly brighter and more intense. It veers more towards the violet spectrum and less towards the brown. A favourite pigment of mine, seen so much in plants! Mix with different yellows for some wonderful muted ochre and brown tones.

As you have seen there are various differences for a number of pigments listed above. There are even slight differences with pigments that have the same index numbers. This variation will most likely be due to different production processes and binders. On one occasion above we saw that a comparison offered up warm and cool versions, W&N Indanthrene Blue and DS Indanthrone Blue. When mixing with these two pigments, the tones would be more muted with Indanthrene Blue and brighter with the DS version. A few DS and W&N pigments have the same name but another colour in the DS range matches more closely.

So, I hope you enjoyed this blog and that it proves useful to you. Thank you for reading and I’ll be back soon with more interesting colour matters.
